General description
BPS-SB-2000C are characterised by good properties in respect of:
· Fatigue strength and wear resistance
· Hardness combined with ductility
· Dimensional tolerances
· Surface and edge finishes
· Shape
Chemical composition (nominal) %
| |
C |
Si |
Mn |
|
BPS-SB-2000C |
1.00 |
0.25 |
0.45 | Standards
EN: 1095
Finishes and forms of supply
BPS-SB-2000C can be supplied in coils or lengths with edges and surfaces described.
Dimensions
BPS-SB-2000C are available in a wide range of sizes. The following chart indicates the approximate stand-size range.
Tolerances
In the standard finish, the tolerances is symmetrical, half above and half below the nominal size. Other tolerances can be discussed in table.
Thickness tolerance
The standard tolerance
Width tolerance, B1
The standard tolerance
Thickness tolerances, T1
See the standard tolerances
Physical properties
The physical properties of a steel are related to a number of factors, including alloying elements, heat treatment and manufacturing route, but the data presented below can generally be used for rough calculations.
Density, g/cm3 ............................................................ 7.85
lb/in3 ......................................................................... 0.28
Thermal expansion per °C, x10 –6 ,
from 20°C to 100°C....................................................... 10.4
to 200°C ..................................................................... 11.6
to 300°C ..................................................................... 12.4
per °F, x 10 –6 ,
from 68°F to 210°F......................................................... 5.8
to 390°F........................................................................ 6.4
to 570°F........................................................................ 6.9
Thermal conductivity
at 20°C, W/(m · °C) ........................................................ 49
68°F, Btu/(ft · h · °F) ....................................................... 28
Mechanical properties Nominal values at 20°C.
| Thickness |
|
Tensile
strength, sRm* |
|
|
|
Proof
strength, Rp0.2 |
|
|
|
| mm.......... |
inch |
BPS-SB-
2000C
MPa |
psi |
BPS-SB-
2000C MPa |
psi |
BPS-SB-
2000C
MPa |
psi |
BPS-SB-2000C
MPa |
psi |
.625-<0.825
0.825-<1.000
1.000-<1.575
1.575-<2.500
2.500-<3.500 |
.032-<.039
.039-<.062
.062-<.098
.098-<.118 |
1600
1550
1500
1500
1500 |
232 000
224 750
217 |
1650
1600
1600
1600 |
500
268 250
261 000 |
1400
1350
1350
1350 |
000
224 750
224 750 |
1500
1450
1450
1450 |
218 000
210 000
210 | Dimensions
Thickness
BPS-SB-2000C is supplied in standard thicknesses in accordance with the table below.
Finishes
Edges
Edges are slit and deburred.
Flatness
Maximum out-of-flatness across and along the steel belt is 0.30% of the nominal steel belt width.
Surfaces
Material is delivered white polished, free from oxide discoloration and with uniform colour and dust free.
Surface roughness
Maximum surface roughness values, cut-off 0.25 mm (.0098 inch), are shown in the table below.
Surface defects
A small number of surface defects, such as pits and roll marks, with a depth or height of up to 15 µm (400 µinch) maximum is allowed. The maximum scratch depth allowed is 22.0 µm (180 µinch).
Straightness
Out-of-straightness is defined as the maximum deviation from a straight-edge of specified length. The following values apply:
| Steel belt width |
|
Maximum allowed deviation |
|
| mm |
inch |
mm/m |
inch/3 feet |
| >50-<125 |
>1.969-<4.921 |
1.25 |
0.045 |
| >1240 |
>4.921 |
3.0 |
0.011 | Disclaimer
Recommendations are for guidance only, and the suitability of a material for a specific application can be confirmed only when we know the actual service conditions. Continuous development may necessitate changes in technical data without notice.
This data sheet is only valid for Biquick material. Other material, covering the same international specifications, does not necessarily comply with the mechanical and corrosion properties presented in this datasheet.
|
|
